产品用途  Product purpose

JCS设备线夹适用于以母线引下线的供电电气设备(如断路器、互感器、隔离开关、穿墙套管等)的出线端连接,产品分单导线出线及双导线出线，产品可选配绝缘罩与线夹配套使用，起绝缘防护作用。测温型设备线夹加装超温报警组件，接头温度过高时动作起警示作用。

JCS wire clamp is suitable for the connecting writing of power supply equipments (such as circuit breaker, transformer,  disconnecting switch, through-wall casing, etc.) with busbar lead wire, and the product is divided into singleconductor and double-conductor wire, and the product can be equipped with optional insulating cover and wire  clamp, which can play the role of insulating and protecting. Temperature test model wire clamps is equipped with  over-temperature alarm components, which act as a warning when the connector temperature is too high.

产品特点  Product feature

◆高强度铝合金制造，无磁滞损耗。

◆Made of strength cast aluminum alloy without magnetic hysteresis loss

◆C形结构，接续可靠。

◆C-shaped structure with reliable connection.

◆适用各种导线组合、应用广泛。

◆Suitable for a wide range of wire combinations and applications

◆线夹与导线接触面积大，接续电阻小。

◆The wire clip has a large contact area with the wire and low splice resistance.
