产品用途  Product purpose

JC线夹适用于20kV及以下架空绝缘导线、铝绞线、铜绞线、钢铝绞线和钢绞线非承受力位置上接续用，产品可选配绝缘置与线夹配套使用，起绝缘防护作用测温型线夹加装超温报警组件，接头温度过高时动作起警示作用。

JC cable clamp is suitable for 20kV and below overhead insulated wires, aluminum stranded wire, copper  stranded wire, steel core aluminum stranded wire and steel stranded wire non-bearing position on the  connection, and the product can be equipped with optional insulating cover and wire clips supporting the use  of insulation protection. Temperature test model cable clamp is equipped with over-temperature alarm  components, which act as a warning when the connector temperature is too high.

产品特点  Product feature

◆高强度铝合金制造，无磁滞损耗。

◆Made of strength cast aluminum alloy without magnetic hysteresis loss

◆C形结构，接续可靠。

◆C-shaped structure with reliable connection

◆适用各种导线组合、应用广泛。

◆Suitable for a wide range of wire combinations and applications.

◆线夹与导线接触面积大，接续电阻小。

◆The wire clip has a large contact area with the wire and low splice resistance.
