产品用途   Product purpose

NXL楔型绝缘耐张线夹适用于10kV及以下配电线路中，将架空绝缘铝导线或裸导线固定在转角或终端耐张杆的绝缘子上，从而将架空导线固定或拉紧，绝缘罩与耐线夹配套使用，起绝缘防护作用。

NXL wedge-type insulated strain clamp is suitable for the distribution line of 10kV and below, and the overhead insulated aluminum wire or bare aluminum wire is fixed on the insulator of the corner or terminal tension rod, so as to fix or tighten the overhead wire, and use the insulation cover in conjunction with the tension wire clamp to play the insulation protection role.

is suitable for the terminal of overhead insulated aluminum core wire (JKLYJ) of 10kV and below or strings the ends of the tensioning section, together with the insulator.

产品特点   Product feature

◆高强度铸造铝合金制造，无磁滞损耗。

◆Manufactured from high-strength cast aluminum alloy without magnetic hysteresis loss.

◆楔型结构，安装简便可靠。

◆Wedge-type structure, which is easy and reliable installation.

◆圆弧大面积抱紧，导线不易滑动、握力大。

◆The arc is held tight over a large area, and the wire is not easy to slide and has a strong grip.
