产品用途  Product purpose

NXG樱型绝缘耐张线夹适用于额定电压10kV及以下钢芯铝绞线架空绝缘电缆(JKLGYJ)的固定和拉紧作用。产品按导线规格分别配有不同的铝合金楔芯。

NXG wedge-type insulated strain clamp is suitable for tensioning the fixing box of steel-core  aluminum stranded overhead insulated cables (JKLGYJ) with rated voltage of 10kV and below. The  product is equipped with different aluminum alloy wedge cores according to wire specifications.

产品特点  Product feature

◆高强度铸造铝合金制造，无磁滞损耗。

◆Made of strength cast aluminum alloy without magnetic hysteresis loss.

◆电缆不需剥除绝缘层，不需使用专用工具即可安装。

◆The cable can be installed without stripping the insulation and without the use of special tools.

◆楔型结构，安装简便可靠。

◆Wedge-type structure, which is easy and reliable installation.
